1SVR730660R0100 ABB Control Industrial Automation Components

ABB 1SVR730660R0100 is an insulation monitor designed with a single threshold insulation monitoring relay function, rated for a DC voltage of 300 V. It features SPDT (Single Pole Double Throw) contacts, with a protection rating of IP20. The device has a communication protocol width of 85.6 mm, a net height of 6 kV, a rated impulse voltage (Uimp) of 22.5 mm, and a rated insulation voltage (Ui) of 103.7 mm. It is suitable for DIN rail mounting and supports a control voltage (AC) with UPC code specifications for power consumption at (24Vdc) 0.9 VA, (115Vac) 2 VA, and (230Vac) 3.2 VA. The monitor accommodates normally closed (NC) auxiliary contacts with varying capacities for flexible and rigid wires, operates within a frequency range of 15-400 Hz, and is designed for supply voltages of (AC/DC) 24-240 V. It has a mechanical endurance of 100,000 operations and an electrical endurance for analog outputs of 30,000,000 operations. The frame current rating varies with the supply voltage, and the device features indicators through green, red, and yellow LEDs for different statuses. The trip unit type is a screw-clamp with a minimum operating temperature of -25°C and is compatible with IT earthing systems. The control circuit rated current and short circuit current breaking capacity are specified for both AC and DC conditions, with a maximum temperature tolerance of +60°C. The operating rate is defined for resistance measurements, and the device is designed for a storage type with a system leakage of 10 µ.
