5269/27C SL005 Alpha Wire Electronic Components

5269/27C SL005 on Advantage Electric Supply
Alpha Wire

Part#:5269/27C SL005

Manufacturer:Alpha Wire

Category:Electronic Components

Product Lifecycle:Active

Product description

Alpha Xtra-Guard®1 Unshielded Multipair Cable - 24 AWG 27 Pair - Slate - 300V - 100 ft

Product Details

  • STANDARDS/APPROVALS
    VW-1 UL 1685
  • VOLTAGE
    300V
  • TEMPERATURE
    105°C
  • NOMINAL OD (MM)
    13.0048
  • MANUFACTURER PART NUMBER
    5269/27C SL005
  • SERIES
    Xtra-Guard 1
  • JACKET COLOR
    Gray
  • NOMINAL OD (IN)
    0.512
  • CONDUCTOR MATERIAL
    Tinned copper
  • JACKET MATERIAL
    PVC
  • SHIELDING
    Unshielded
  • NUMBER OF CONDUCTORS
    27 pair
  • AWG/GAUGE
    24
  • CONDUCTOR STRANDING
    Stranded

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

5269/27C SL005 Related Documents

Datasheet.pdf

Manufacturer warranty
