Advantage Electric Supply Logo

ARC Eaton Industrial Automation Components

ARC on Advantage Electric Supply
Eaton

Part#:ARC

Manufacturer:Eaton

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

ARC Eaton - Eaton NEMA machine tool relay, AR/ARD Machine Tool Standard Contact Cartridge, 600V max. voltage rating, AC cartridge, Clamp terminals

Product Details

  • Weight
    .07 pounds
  • Voltage
    600 volts
  • Type
    AR/ARD Machine Tool Standard Contact Cartridge
  • Length
    2 inches
  • Terminal Type
    Clamp
  • Height
    2 inches
  • Contact Voltage Rating:
    600 VAC
  • Terminal Type:
    Clamp
  • Used On:
    AR/ARD Series Machine Tool Relay
  • UPC:
    786678259475
  • Shipping Width:
    2.00 In.
  • Approval:
    UL
  • Type:
    Convertible Standard AC Cartridge
  • Shipping Height:
    2.00 In.
  • Series:
    ARC
  • Shipping Length:
    3.00 In.
  • Shipping Weight:
    0.05 lbs.

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
