DH262FRK Eaton Industrial Automation Components
Part#:DH262FRK
Manufacturer:Eaton
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
DH262FRK Eaton - Eaton Enhanced visible blade single-throw safety switch, 60 A, NEMA 3R, Painted galvanized steel, Class H, Fusible without neutral, Two-pole, Two-wire, 600 V, Max Hp: 20, 25 hp/25 hp (1PH @480,600 V TD/600 Vdc), #14-#2 Cu/Al
Product Details
- Product Name Eaton enhanced visible blade single-throw fused safety switch
- Enclosure material Painted galvanized steel
- Voltage rating 600 V
- Certifications UL Listed
- HP rating - max 20, 25 hp/25 hp (1PH @480,600 V TD/600 Vdc)
- Catalog Number DH262FRK
- Fuse class provision Class H
- Product Height 16.27 in
- Product Length/Depth 17 in
- Wire size #14-2 AWG Cu/Al
- UPC 786685177137
- Number Of Poles Two-pole
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Product Category Heavy Duty, Fusible without neutral
- Product Weight 18 lb
- Number of wires 2
- Product Width 9.5 in
- Fuse configuration Fusible without neutral
- Amperage Rating 60A
- Height 16.27 inches
- Enclosure 3R
- Amperage 60 amperes
- Number of Poles 2
- Enclosure Material Painted Galvanized Steel
- Voltage 600 volts
- Weight 18 pounds
- Length 17 inches
- Type Heavy Duty Fusible Safety Switch
- Shipping Width: 10.00 In.
- Enclosure Material: Steel
- Size: 8.13 Inch Width x 10 Inch Depth x 15.88 Inch Height
- UPC: 786685177137
- Poles: 2
- Shipping Length: 17.00 In.
- Fuse Type: Class H
- AC Voltage: 480 to 600 V
- Fuse Provision: Fusible
- DC Voltage: 600 V
- Number of Wires: 2
- Amps: 60 A
- Finish: Painted Galvanized
- Shipping Height: 9.00 In.
- Enclosure: NEMA 3R
- Power: 25 HP at 600 Volt AC 1-Phase (Time Delay)
- Shipping Weight: 14.40 lbs.
- Neutral Type: No
- Approval: UL
- Series: 0
- Type: Heavy Duty
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DH262FRK on Advantage Electric Supply is $3,107.31. Order now.
