DH322FRK Eaton Industrial Automation Components
Part#:DH322FRK
Manufacturer:Eaton
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
DH322FRK Eaton - Eaton Enhanced visible blade single-throw safety switch, 60 A, NEMA 3R, Painted galvanized steel, Class H, Three-pole, Three-wire, 240 V, Max Hp: 3, 7.5/ 10, 15/ 10 hp (1,3PH @Std/TD/250 Vdc), #14-#2 Cu/Al
Product Details
- Catalog Notes Suitable for service entrance use with a Neutral Kit installed
- Product Category Heavy Duty, Fusible without neutral
- Voltage rating 240V
- Product Weight 14 lb
- Product Width 9.5 in
- Product Length/Depth 16.5 in
- Certifications UL Listed
- Catalog Number DH322FRK
- Product Height 16.27 in
- Wire size #14-2 AWG Cu/Al
- Enclosure material Painted galvanized steel
- Amperage Rating 60A
- Type Heavy Duty Fusible Safety Switch
- UPC 782113205816
- Fuse class provision Class H
- Number Of Poles Three-pole
- Number of wires 3
- Fuse configuration Fusible without neutral
- Product Name Eaton enhanced visible blade single-throw fused safety switch
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- HP rating - max 3, 7.5/ 10, 15/ 10 hp (1,3PH @Std/TD/250 Vdc)
- Shipping Width: 17.00 In.
- Fuse Type: Cartridge
- Shipping Height: 10.00 In.
- Amps: 60 A
- Series: DH
- Enclosure: NEMA 3R
- Fuse Provision: Fusible
- Finish: Painted Galvanized
- UPC: 78211320581
- Number of Wires: 3
- Size: 9.89 Inch W x 7.75 Inch D x 16.27 Inch H
- Power Rating: 3 HP at 240 VAC 1-Phase
- AC Voltage Rating: 240 V
- Shipping Weight: 14.00 lbs.
- Poles: 3
- Shipping Length: 9.00 In.
- Neutral Type: No
- TS PIK: 111011466
- Approval: UL 98
- Enclosure Material: Steel
- Type: Heavy Duty Safety
- DC Voltage Rating: 250 V
- Length 16.5 inches
- Height 16.27 inches
- Enclosure 3R
- Weight 14 pounds
- Amperage 60 amperes
- Enclosure Material Painted Galvanized Steel
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DH322FRK on Advantage Electric Supply is $2,453.28. Order now.
