DH465FDKW Eaton Industrial Automation Components
Part#:DH465FDKW
Manufacturer:Eaton
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
DH465FDKW Eaton - Eaton Heavy duty single-throw fused safety switch, Enhanced visible blade, 4 blade, 400 A, NEMA 12/3R, Cartridge, Four-wire, 600 V, Max Hp: 250, 350/ 50 hp (480,600 V @3PH/250 Vdc), 600 V, (2)#1/0-(2)300 kcmil; or (1)#1/0-(1)750 kcmil Cu/Al
Product Details
- Product Width 25.5 in
- Series K
- Catalog Number DH465FDKW
- Product Length/Depth 64 in
- Fuse class provision Cartridge
- Enclosure material Painted galvanized steel
- Product Weight 123 lb
- Number of wires 4
- UPC 786680181047
- Voltage - max 600 V
- Product Height 13 in
- Number Of Poles Four-pole
- Certifications UL Listed
- HP rating - max 250, 350/ 50 hp (480,600 V @3PH/250 Vdc)
- Type Heavy Duty Fusible Safety Switch
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Special features Enhanced visible blades, 4 blade, upper viewing window
- NEMA rating NEMA 12, NEMA 3R
- Catalog Notes Heavy Duty Safety Switch (HDSS), w/ Enhanced Visible Blade
- Fuse configuration Fusible without neutral
- Product Name Eaton heavy duty single-throw fused safety switch
- Voltage rating 600 V
- Amperage Rating 400A
- Enclosure NEMA 12, NEMA 3R
- Application Heavy commercial and industrial
- Width 25.5 inches
- Number of Poles 4
- Height 13 inches
- Length 64 inches
- Voltage 600 volts
- Amperage 400 amperes
- Enclosure Material Painted Galvanized Steel
- Weight 123 pounds
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of DH465FDKW on Advantage Electric Supply is $23,273.31. Order now.
