FDC3125VU62 Eaton Industrial Automation Components
Part#:FDC3125VU62
Manufacturer:Eaton
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
FDC3125VU62 Eaton - Eaton Series C complete molded case circuit breaker, F-frame, FDC, Fixed thermal and magnetic trips, Three-pole, 125A, 600 Vac, 250 Vdc, 200 kAIC at 240 Vac, 100 kAIC at 480 Vac, Load side, 110-127 Vac rear w/ right pigtail, 50°C, 50/60 Hz
Product Details
- UPC 786679082294
- Frame F
- Product Length/Depth 3.38 in
- Circuit breaker frame type Complete breaker
- Catalog Number FDC3125VU62
- Circuit breaker type FDC
- Product Weight 4.5 lb
- Frequency rating 50/60 Hz
- Interrupt rating 100 kAIC at 480 Vac 200 kAIC at 240 Vac
- Terminals Load side
- Product Height 4.13 in
- Calibration 50°C
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Product Name Eaton Series C complete molded case circuit breaker
- Number of poles Three-pole
- Product Width 4.13 in
- Undervoltage release 110-127 Vac rear with right pigtail
- Certifications UL Listed
- Series Series C
- Voltage rating 600 Vac, 250 Vdc
- Amperage Rating 125 A
- Length 3.38 inches
- Amperage 125 amperes
- Trip Type Fixed Magnetic, Fixed Thermal
- Circuit Breaker Type FDC
- Terminal Type Load Side
- Weight 4.5 pounds
- Frequency 50 hertz, 60 hertz
- Height 4.13 inches
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
