H48M22T3316 Eaton Electronic Components
Part#:H48M22T3316
Manufacturer:Eaton
Category:Electronic Components
Product Lifecycle:Active
Product description
Eaton K-Factor nonlinear ventilated transformer, Aluminum windings, NEMA 2, FRFloor, 60 Hz, 220C, 300 kVA, Three-Phase, 480 DELTA to 240 DELTA 120V LIGHTING TAP (PH B), 150 C rise, Shielded, DOE 2016, WS62, , K4
Product Details
- Product Width 42.18 in
- Insulation 220 °C
- Mounting Floor
- Compliances DOE2016 Efficient
- Tap size 2 at +2.5%, 4 at -2.5%
- Secondary Voltage 240 V delta, 120 V Midtap
- UPC 786680243202
- Frame Floor
- Kva Rating 300 kVA
- Temperature rise 150 °C rise
- Certifications UL Listed
- Primary voltage 480 V
- Coil material Aluminum
- Catalog Number H48M22T3316
- Modification 1 Electrostatic shield
- Frequency rating 60 Hz
- Product Length/Depth 33.5 in
- Special features K-factor 4
- Enclosure NEMA 2
- Volt ampere rating 300 kVA
- Product Name Eaton K-Factor nonlinear ventilated transformer
- Sound Level NEMA ST-20
- Product Height 66.18 in
- Weathershield WS62
- Type Energy-efficient ventilated transformer
- Catalog Notes 10 CFR Part 431 (2016) Efficient
- Wiring connection 284B
- Product Weight 2622 lb
- Phase Three-phase
- Efficiency 10 CFR Part 431-2016 (DOE 2016)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of H48M22T3316 on Advantage Electric Supply is $104,595.34. Order now.
Manufacturer warranty
H48M22T3316 Eaton
$104,595.34
Your price can be lower.
Log in or Create account to check your discount
Backordered – place your order now, and we’ll take care of the rest
Select Qty:
$104,595.34
$104,595.34 each
Your order is guaranteed – we’ll keep you updated on delivery timelines
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
