PDD23N0125TFFL Eaton Industrial Automation Components
Part#:PDD23N0125TFFL
Manufacturer:Eaton
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
PDD23N0125TFFL Eaton - Eaton Power Defense molded case circuit breaker, UL/CSA 240V Max, Frame 2, Three Pole, 125A, 150kA/240V, T-M (Fxd-Fxd) TU, Standard Terminals Load Only (PDG2X3TA225)
Product Details
- Voltage rating 240 V AC
- Interrupt rating range 150 kAIC @240V (UL) 22 kAIC Icu @250 Vdc 22 kAIC Icu @125 Vdc
- Product Name Eaton Power Defense molded case circuit breaker
- Interrupt rating 150 kAIC at 240 Vac
- Switch off technique Thermomagnetic
- Terminals Standard Terminals Load Only
- Product Height 152.4 mm
- Amperage Rating 125 A
- Trip Type T-M (Fxd-Fxd) TU
- Product Length/Depth 88.9 mm
- Product Width 104.6 mm
- Compliances RoHS Compliant
- Rated operation voltage (Ue) at AC - max 240
- Number of poles Three-pole
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Circuit breaker type PD2 UL/CSA Only
- Catalog Number PDD23N0125TFFL
- Product Weight 1.82 kg
- Frame 2
- Voltage rating - max 240 V
- Circuit breaker frame type Complete breaker
- UPC 786687039921
- Certifications UL 489 CSA
- Class Class A
- Weight 1.82 kilograms
- Length 88.9 millimeters
- Voltage 240 volts
- Amperage 125 amperes
- Circuit Breaker Type PD2 Global
- Height 152.4 millimeters
- Terminal Type Standard Terminals Load Only
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
