PDG32F0250P2WJ Eaton Molded Case Circuit Breakers (MCCB)
Part#:PDG32F0250P2WJ
Manufacturer:Eaton
Category:Molded Case Circuit Breakers (MCCB)
Product Lifecycle:Active
Product description
Eaton Power Defense molded case circuit breaker, Globally Rated, Frame 3, Two Pole, 250A, 25kA/480V, PXR25 LSI w/ Modbus RTU, ZSI and Relays, Standard Line and Load (PDG3X2TA350)
Product Details
- Special features ZSI / Modbus / Relays
- Circuit breaker frame type Complete breaker
- Trip Type PXR 25 LSI
- Catalog Number PDG32F0250P2WJ
- Rated operation voltage (Ue) at AC - max 600
- Class Class A
- Compliances RoHS Compliant
- Circuit breaker type PD3 Global
- Product Name Eaton Power Defense molded case circuit breaker
- Product Width 138.9 mm
- Switch off technique Electronic
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Voltage rating - max 600 V
- Communication Modbus RTU
- Amperage Rating 250 A
- UPC 786679541609
- Interrupt rating 25 kAIC at 480 Vac
- Voltage rating 600 Vac
- Product Height 257.1 mm
- Frame 3
- Interrupt rating range 25 kAIC Icu/ 25 kAIC Ics/ 52.5 kAIC Icm @380-415V (IEC) 14 kAIC @600V (UL/CSA) 35 kAIC Icu/ 35 kAIC Ics/ 73.5 kAIC Icm @240V (IEC) 20 kAIC Icu/ 20 kAIC Ics/ 42 kAIC Icm @480V Brazil (IEC) 25 kAIC @480V (UL) 25 kAIC Icu/ 20 kAIC Ics/ 52.5 kAIC Icm @44
- Product Length/Depth 109.1 mm
- Number of poles Two-pole
- Product Weight 5.2163 kg
- Certifications IEC 60947-2 UL 489 CCC Marked CSA
- Terminals Standard Line and Load
