PDG32F0250P5WL Eaton Molded Case Circuit Breakers (MCCB)
Part#:PDG32F0250P5WL
Manufacturer:Eaton
Category:Molded Case Circuit Breakers (MCCB)
Product Lifecycle:Active
Product description
Eaton Power Defense molded case circuit breaker, Globally Rated, Frame 3, Two Pole, 250A, 25kA/480V, PXR25 ARMS LSIG w/ Modbus RTU, ZSI and Relays, Standard Terminals Load Only (PDG3X2TA350)
Product Details
- Product Length/Depth 109.1 mm
- Circuit breaker type PD3 Global
- Product Weight 5.2163 kg
- Amperage Rating 250 A
- Product Width 138.9 mm
- Special features ZSI / Modbus / Relays
- Circuit breaker frame type Complete breaker
- Compliances RoHS Compliant
- Rated operation voltage (Ue) at AC - max 600
- Terminals Standard Terminals Load Only
- Catalog Number PDG32F0250P5WL
- Switch off technique Electronic
- Communication Modbus RTU
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Certifications UL 489 CSA CCC Marked IEC 60947-2
- Class Class A
- Product Name Eaton Power Defense molded case circuit breaker
- Interrupt rating 25 kAIC at 480 Vac
- Interrupt rating range 35 kAIC Icu/ 35 kAIC Ics/ 73.5 kAIC Icm @240V (IEC) 18 kAIC Icu/ 5 kAIC Ics/ 37.8 kAIC Icm @525V South Africa (IEC) 20 kAIC Icu/ 20 kAIC Ics/ 42 kAIC Icm @480V Brazil (IEC) 25 kAIC Icu/ 25 kAIC Ics/ 52.5 kAIC Icm @380-415V (IEC) 14 kAIC @600V (UL/CSA)
- Product Height 257.1 mm
- Voltage rating - max 600 V
- Frame 3
- Voltage rating 600 Vac
- UPC 786679810934
- Number of poles Two-pole
- Trip Type PXR 25 LSIG w/ARMS
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
Manufacturer warranty
PDG32F0250P5WL Eaton
Get a quick Quote!
Request a quote, and we will send you price and availability within minutes.
Select Qty:
Average response time: 11 minutes
Fast Shipping & Delivery
We deliver nationwide and international
Secure Payment Processing
with money back guarantee
Warranty On All Parts
Manufacturer warranty
Responsive Customer Support
Let us know how we can help!
Need more details?
Feel free to chat with us
Compare PDG32F0250P5WL with other Molded Case Circuit Breakers (MCCB) products
Product Length/Depth
Circuit breaker type
Product Weight
Amperage Rating
Product Width
Special features
Circuit breaker frame typ...
Compliances
Rated operation voltage (...
Terminals
Selected product
PDG32F0250P5WL
Eaton
Eaton Power Defense molded case circuit breaker, Globally Rated, Frame 3, Two Pole, 250A, 25kA/480V,...
Product Length/Depth109.1 mm
Circuit breaker typePD3 Global
Product Weight5.2163 kg
Amperage Rating250 A
Product Width138.9 mm
Special featuresZSI / Modbus / Relays
Circuit breaker frame typeComplete breaker
CompliancesRoHS Compliant
Rated operation voltage (Ue) at AC - max600
TerminalsStandard Terminals Load Only
Product Length/Depth-
Circuit breaker type-
Product Weight-
Amperage Rating-
Product Width-
Special features-
Circuit breaker frame type-
Compliances-
Rated operation voltage (Ue) at AC - max-
Terminals-
About the manufacturer
Advantage Electric Supply is an authorized Eaton distributor, dedicated to bringing you the highest-quality industrial solutions. Eaton, a global leader in power management and electrical components, specializes in a wide array of products designed to optimize operational efficiency and enhance safety across various industries. From electrical control systems to cutting-edge automation technologie...
About the Product Category
An MCCB, or Molded Case Circuit Breaker, is an electrical safety device that automatically disconnects electrical power when it identifies an overload, short circuit, or ground fault. Its purpose is to safeguard an electrical circuit from harm due to excessive current caused by an overload or short circuit.
