XTCE007B10A Eaton Industrial Automation Components
Part#:XTCE007B10A
Manufacturer:Eaton
Category:Industrial Automation Components
Product Lifecycle:Active
Jul 30, 2025
Product description
XTCE007B10A Eaton - Eaton XT IEC contactor, 7A, 110 Vac 50 Hz, 120 Vac 60 Hz, 1NO, 7A, Frame B, 45 mm, 50-60 Hz, 0.25, 0.75, 1/ 1.5, 2, 3, 5 hp (1/3PH @115, 200, 230/200, 230, 460, 575 V), Three-pole, Screw terminals, Full voltage non-reversing contactor
Product Details
- Compliances CE Marked RoHS Compliant
- Frequency rating 50-60 Hz
- Catalog Number XTCE007B10A
- HP rating - max 0.25, 0.75, 1/ 1.5, 2, 3, 5 hp (1/3PH @115,200,230/200,230,460,575 V)
- Continuous ampere rating 7 A
- EAN 4015082765477
- Number Of Poles Three-pole
- Series XT IEC
- Product Length/Depth 2.95 in
- Coil 110-120 Vac, 50/60 Hz
- Certifications UL Listed CSA Certified IEC 60947 EN 60947
- Contact configuration 1 NO
- Product Width 1.77 in
- Type Full Voltage Non-reversing Contactor
- Catalog Notes Screw terminals (6-65A); 5 mm (80-150A); no lugs (185-2000A)
- Frame size 45 mm
- Product Name Eaton XT IEC contactor
- Coil voltage 110-120 Vac, 50/60 Hz
- Product Weight .5 lb
- Amperage Rating 7A
- Terminals Screw terminals
- Product Height 2.67 in
- Operation Non-reversing
- Shipping Length: 2.00 In.
- Enclosure: IP20
- Type: Full Voltage
- Shipping Weight: 0.55 lbs.
- Shipping Width: 3.00 In.
- UPC: 15082765471
- Size: IEC B
- Auxiliary Contact: 1NO
- Amps: 7 A
- Construction Standard: IEC
- Approval: UL
- Poles: 3
- Shipping Height: 3.00 In.
- Series: XT
- Coil Voltage: 110/120 VAC 50/60 Hertz
- Power/Voltage: 1/4 HP at 115 Volt AC 1-Phase
- Amperage 7 amperes
- Contact Configuration 1NO
- Length 2.95 inches
- Coil Voltage 110/120 volts, 120 volts
- Frame 45 millimeters
- Height 2.67 inches
- Terminal Type Screw Terminals
- Weight .5 pounds
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
