34.51.7.060.5310 Finder Control Relays

34.51.7.060.5310 on Advantage Electric Supply
Finder

Part#:34.51.7.060.5310

Manufacturer:Finder

Category:Control Relays

Product Lifecycle:Active

Product description

Finder 34.51.7.060.5310 is a relay designed with 1 Normally Open (NO) pole and solder pin connections. It supports a rated current of 6A at 250Vac (AC-1), 3A at 30Vdc, 0.2A at 110Vdc, and 0.12A at 220Vdc for Normally Open (NO) auxiliary contacts. The supply voltage is specified for 1NO / SPST-NO configurations, with an ambient air temperature for operation at 250VA (230Vac) and for storage at 1500VA (250Vac). This relay operates within an ambient temperature range of -40 to +85 degrees Celsius and features a communication protocol of type C. It has a net width of 60Vdc, offers protection functions at 250Vac, and a control voltage (AC) of 6 kV. The rated active power is for 1 Pole(s), with a response time of 0.17 W, and it is designed for up to 60,000 operations. The relay's contacts are made of AgNi+Au (Gold plated silver-nickel), indicating its suitability for PCB or plug-in applications.

Product Details

  • Product series / family name
    34 series
  • Rated current
    6A (250Vac; AC-1) 3A (30Vdc; DC-1) 0.2A (110Vdc; DC-1) 0.12A (220Vdc; DC-1)
  • Contacts type
    1NO / SPST-NO (Single Pole Single Throw - Normally Open)
  • Rated impulse voltage (Uimp)
    6 kV
  • Poles
    1 Pole(s)
  • Mounting mode
    PCB Plug-in
  • Electrical durability (with load)
    60 000 operations
  • Main function
    Relay
  • Connection type
    Solder pin
  • Degree of protection
    RT II
  • Power consumption
    0.17 W
  • Primary brand
    Finder
  • Rated voltage (AC)
    250Vac
  • Control Voltage (DC)
    60Vdc
  • Ambient air temperature for operation
    -40...+85 °C
  • Contacts coating
    AgNi+Au (Gold plated silver-nickel)
  • Rated power
    250VA (230Vac; AC-15) 1500VA (250Vac; AC-1) 0.17W
  • Number of Normally Open (NO) circuits
    1 NO Pole(s)
  • Compliant with standard(s)
    cURus CCC RINA VDE EAC EN 61000-4-2 EN 61000-4-3 EN 61000-4-4 EN 61000-4-5 EN 61000-4-6 EN 61810-1 EN 62314

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.

34.51.7.060.5310 Related Documents

Finder - 34 Series - Catalogue.pdf
