56.32.8.240.0030 Finder Control Relays
Part#:56.32.8.240.0030
Manufacturer:Finder
Category:Control Relays
Product Lifecycle:Active
Product description
Finder 56.32.8.240.0030 is a relay with a connection type of Fast-on 187, designed for a rated current of 12A at both 250Vac (AC-1) and 30Vdc (DC-1), with lower current ratings of 0.5A at 110Vdc and 0.25A at 220Vdc for Normally Open (NO) auxiliary contacts in DC-1 design. It operates with a supply voltage of 2C/O / DPDT (Double Pole Double Throw), capable of handling ambient air temperatures from -40 to +70 degrees Celsius for operation and is specified for AC-15 usage at 700VA (230Vac) and AC-1 usage at 3000VA (250Vac) for ambient air temperature storage. The rated voltage for AC operation is 250Vac, with a control voltage (AC) of 240Vac (50Hz/60Hz) and a protection function rated at 4 kV. This relay is designed for a rated active power of 2 poles, features a plug-in design for residual current sensitivity, and supports up to 100,000 operations for Normally Closed (NC) circuits. The contact material is AgNi (Silver Nickel), and it is designed for 20,000,000 operations, indicating its durability and longevity in applications.
Product Details
- Rated power 700VA (230Vac; AC-15) 3000VA (250Vac; AC-1)
- Contacts type 2C/O / DPDT (Double Pole Double Throw)
- Primary brand Finder
- Rated voltage (AC) 250Vac
- Poles 2 Pole(s)
- Mechanical durability (at no load) 20 000 000 operations
- Control Voltage (AC) 240Vac (50Hz/60Hz)
- Mounting mode Plug-in
- Connection type Fast-on 187
- Contacts coating AgNi (Silver Nickel)
- Electrical durability (with load) 100 000 operations
- Rated impulse voltage (Uimp) 4 kV
- Rated current 12A (250Vac; AC-1) 12A (30Vdc; DC-1) 0.5A (110Vdc; DC-1) 0.25A (220Vdc; DC-1)
- Ambient air temperature for operation -40...+70 °C
- Main function Relay
- Compliant with standard(s) cURus Lloyd Register (LR) CCC EN EC RINA CSA VDE EAC CE EN 61000-4-4 EN 61000-4-5 EN 61810-1
- Product series / family name 56 series
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
