AC2219 ifm Electronic Electronic Components
Part#:AC2219
Manufacturer:ifm Electronic
Category:Electronic Components
Product Lifecycle:Active
Product description
AS-Interface control cabinet module, For use in control cabinets, Application: I/O modules for control cabinet installations
Product Details
- Application I/O modules for control cabinet installations
- Number of analog outputs 4; (Anschluss von 2-Draht-Aktuatoren oder 4-Draht-Aktuatoren mit separater 24 V-Versorgung)
- Additional voltage supply [V] 24 DC; (to PELV)
- Max. current consumption from AS-i [mA] 57; (with external supply: 25 mA)
- Reverse polarity protection yes
- Min. load resistance [Ω] 1000
- Operating voltage [V] 26.5...31.6 DC; (cULus - Class 2 source required)
- Actuator supply outputs AS-i / AUX
- Max. current load total [A] 0.5; (with external supply; with external supply: 100 mA)
- Max. load [Ω] 600
- Additional voltage supply optional
- Overload protection yes
- Current consumption [mA] 12...57; (External supply)
- Analog voltage output [V] 0...10
- Number of inputs and outputs Number of analog outputs: 4
- Resolution of analog output 16 (1 bit = 1 µV)
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
