IM5040 ifm Electronic Electronic Components

Name: IM5040
Brand: ifm Electronic

Part#:IM5040

Manufacturer:ifm Electronic

Category:Electronic Components

Product Lifecycle:Active

Product description

Inductive sensor, Long sensing range for use in conveying, Electrical design: NPN, Output function: normally open / closed; (selectable), Sensing range [mm]: 15, Housing: rectangular, Dimensions [mm]: 40 x 40 x 120

Product Details

Current consumption [mA]
15; (24 V)
Electrical design
NPN
Switching frequency DC [Hz]
350
Dimensions [mm]
40 x 40 x 120
Operating voltage [V]
10...36 DC
Short-circuit protection
yes
Type of short-circuit protection
yes (non-latching)
Reverse polarity protection
yes
Protection class
II
Sensing range [mm]
15
Housing
rectangular
Permanent current rating of switching output DC [mA]
250
Overload protection
yes
Output function
normally open / closed; (selectable)
Max. voltage drop switching output DC [V]
2.5

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
