O2D229 ifm Electronic Electronic Components
Part#:O2D229
Manufacturer:ifm Electronic
Category:Electronic Components
Product Lifecycle:Active
Product description
Object recognition sensor, For presence, completeness, position and quality control, Type of light: Infrared light, Image resolution [px]: 640 x 480, Max. reading rate [Hz]: 20, Communication interface: Ethernet, Dimensions [mm]: 60 x 42 x 53.5
Product Details
- Type of light Infrared light
- Number of inputs and outputs Number of digital inputs: 2; Number of digital outputs: 5
- Output function 24 V NPN
- Max. reading rate [Hz] 20
- Wave length [nm] 850
- Short-circuit protection yes
- Operating voltage [V] 24 DC
- Total number of outputs 5
- Max. current load per output [mA] 100
- Image resolution [px] 640 x 480
- Image sensor CMOS image sensor black/white
- Max. voltage drop switching output DC [V] 2
- Operating voltage tolerance [%] 10
- Reverse polarity protection yes
- Input circuit of digital inputs 24 V PNP; (configurable; IEC 61131-2 Typ 1)
- Protection class III
- Trigger 24 V NPN (IEC 61131-2 Typ 1); internal
- Overload protection yes
- Current consumption [mA] 300
- Number of digital outputs 5; (configurable)
- Dimensions [mm] 60 x 42 x 53.5
- Communication interface Ethernet
- Number of digital inputs 2
