PE3000 ifm Electronic Electronic Components

Product Details

• Current consumption [mA]
  < 50
• Integrated watchdog
  yes
• Output signal
  switching signal; analog signal; (configurable)
• Analog current output [mA]
  4...20
• Media
  liquids and gases
• Overvoltage protection
  yes; (< 40 V)
• Cannot be used for
  oils
• Min. bursting pressure
  1000 bar 14500 psi 100 MPa
• Type of short-circuit protection
  yes (non-latching)
• Max. voltage drop switching output DC [V]
  2
• Output function
  normally open / closed; (configurable)
• Max. load [Ω]
  500
• Application
  for industrial applications
• Operating voltage [V]
  18...36 DC; (according to EN 50178 SELV/PELV)
• Min. insulation resistance [MΩ]
  100; (500 V DC)
• Total number of outputs
  2
• Switching frequency DC [Hz]
  < 170
• Conditionally suitable for
  use in gases at pressures > 25 bar only on request
• Number of digital outputs
  1
• System
  gold-plated contacts
Protection class
III
Min. load resistance [Ω]
2000
Process connection
threaded connection G 1/4 Internal thread
Analog voltage output [V]
0...10
Medium temperature [°C]
-25...80
Type of pressure
relative pressure
Pressure rating
600 bar 8700 psi 60 Mpa
Number of inputs and outputs
Number of digital outputs: 1; Number of analog outputs: 1
Number of analog outputs
1
Measuring range
0...400 bar 0...5800 psi 0...40 MPa
Permanent current rating of switching output DC [mA]
250
Power-on delay time [s]
0.3
Short-circuit protection
yes
Electrical design
PNP
Reverse polarity protection
yes
