SM8001 ifm Electronic Electronic Components

Product Details

• Number of inputs and outputs
  Number of digital outputs: 2; Number of analog outputs: 1
• Operating voltage [V]
  18...30 DC; (according to EN 50178 SELV/PELV)
• Output signal
  switching signal; analog signal; pulse signal; IO-Link; (configurable)
• Analog voltage output [V]
  0...10; (scalable)
• Pressure rating [psi]
  232
• Installation
  connection to pipe by means of an adapter
• Number of digital outputs
  2
• Overload protection
  yes
• Process connection
  threaded connection G 1 DN25 flat seal
• Total number of outputs
  2
• Min. load resistance [Ω]
  2000
• Pressure rating [bar]
  16
• System
  gold-plated contacts
• Electrical design
  PNP/NPN
• Max. load [Ω]
  500
• Note on media
  conductivity: ≥ 20 µS/cm viscosity: < 70 mm²/s (40 °C)
• Reverse polarity protection
  yes
• Output function
  normally open / closed; (configurable)
• Short-circuit protection
  yes
• Measuring range
  6...1584 gph 0.1...26.4 gpm
Current consumption [mA]
95; (24 V)
Max. voltage drop switching output DC [V]
2
Type of short-circuit protection
yes (non-latching)
Power-on delay time [s]
5
Number of analog outputs
1
Media
Conductive liquids; water; water-based media
Medium temperature [°F]
14...158
MAWP (for applications according to CRN) [bar]
11.2
Inputs
counter reset
Analog current output [mA]
4...20; (scalable)
Permanent current rating of switching output DC [mA]
200
Pulse output
flow rate meter
Application
Totalizer function; for industrial applications
Protection class
III
