221818 Lapp Industrial Automation Components
Part#:221818
Manufacturer:Lapp
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
221818 Lapp - ÖLFLEX TRAY II 18G1 18/18C
Product Details
- NUMBER OF CONDUCTORS 18
- JACKET COLOR Black
- STANDARDS/APPROVALS UL Approved CSA Approved CE Approved
- SERIES ÖLFLEX® TRAY II / TRAY II CY
- DYNAMIC TEMPERATURE RATING -13°F to +221°F -25°C to +105°C
- UL STYLE / STANDARD UL 13 UL 1063 UL 1277 UL 1690 UL 2250
- CONDUCTOR MATERIAL Bare copper
- TEMPERATURE RANGE -13°F to +194°F -25°C to +90°C
- MANUFACTURER PART NUMBER 221818
- NOMINAL OD (MM) 14.9
- VOLTAGE 600V
- JACKET MATERIAL Thermoplastic Polymer
- SHIELDING Unshielded
- NOMINAL OD (IN) 0.587
- CONDUCTOR COLOR Black with white printing plus green/yellow ground
- WEIGHT LBS/MFT 245
- INSULATION PVC/Nylon
- TRAY RATINGS UL ITC-ER UL PLTC-ER UL TC-ER
- AWG/GAUGE 18
- STATIC TEMPERATURE RATING -40°F to +221°F-40°C to +105°C
- APPLICATION Industrial plant expansions; automotive plants; tray wiring; anywhere VNTC® cables are used
- CONDUCTOR STRANDING Stranded
- ATTRIBUTES UL Oil Res I/IISunlight resistant Direct burialNFPA 79
- Insulation Material Nylon, PVC
- Conductor Material Finely Stranded Bare Copper
- Jacket Color Black
- Gauge 18 american wire gauge
- Operating Temperature -25 degrees celsius, 90 degrees celsius
- Bend Radius 4 X Cable Diameter
- Jacket Material Thermoplastic Polymer
- Stranding Class 5 Fine Wire
- Voltage 600 volts
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Tray Cable, ÖLFLEX TRAY II, 18 AWG/18C, 600V, UL TC-ER, UL MTW, c(UL) CIC/TC FT4
