601625 Lapp Industrial Automation Components
Part#:601625
Manufacturer:Lapp
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
601625 Lapp - ÖLFLEX 190 25G1.5 16/25C
Product Details
- NOMINAL OD (MM) 18.6
- VOLTAGE 600V
- STANDARDS/APPROVALS UL Approved CSA Approved CE Approved
- NOMINAL OD (IN) 0.733
- DYNAMIC TEMPERATURE RATING -13°F to +194°F-25°C to +90°C
- CONDUCTOR COLOR Black with white printing plus green/yellow ground
- TEMPERATURE -13°F to +194°F -25°C to +90°C
- TRAY RATINGS UL TC-ER
- CONDUCTOR STRANDING Stranded
- MANUFACTURER PART NUMBER 601625
- JACKET COLOR Gray
- ATTRIBUTES UL Oil Res I/IISunlight resistant Direct burialNFPA 79
- AWG/GAUGE 16
- INSULATION PVC
- UL STYLE / STANDARD UL 13 UL 2277
- CONDUCTOR MATERIAL Bare copper
- JACKET MATERIAL Thermoplastic Polymer
- WEIGHT LBS/MFT 417
- SERIES ÖLFLEX® 190 / 190 CY
- SHIELDING Unshielded
- NUMBER OF CONDUCTORS 25
- STATIC TEMPERATURE RATING -40°F to +221°F-40°C to +105°C
- Conductor Material Finely Stranded Bare Copper
- Voltage 600 volts
- Gauge 16 american wire gauge
- Insulation Material PVC
- Bend Radius 4 X Cable Diameter
- Operating Temperature -40 degrees celsius, 105 degrees celsius
- Stranding Class 5 Fine Wire
- Jacket Color Gray
- Jacket Material Thermoplastic Polymer
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Cable, Flexible, ÖLFLEX 190, 16 AWG/25C, 600V, UL TC-ER, UL AWM, CSA AWM FT4
