CTSM-40R Mencom Electronic Components

Name: CTSM-40R
Brand: Mencom
Price: 224.25 USD
Availability: BackOrder

Part#:CTSM-40R

Manufacturer:Mencom

Category:Electronic Components

Product Lifecycle:Active

Product description

Standard, CTS series, Male Rectangular Insert, size 77.27, 40 pin, 10 amp, Standard Spring Right ground

Product Details

Insert Dimension
77.27
Amperage Rating
10
Temperature Range in Degrees Celsius
-40 C to +125 C
Component Type
Insert
Voltage Rating
600
Number of Entries
0
Termination
Standard Spring
ILME Series
CTS
Gender
Male
Housing/Insert Type
Standard
Lower AWG
26
Gasket/O-Ring
No
Product Type
Rectangular Connectors
Pin Count
40
Contact Plating
Silver
Enclosure Dimension
77.27
Weight (lbs.)
0.816000
Upper AWG
14
Cover
No

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of CTSM-40R on Advantage Electric Supply is $224.25. Order now.

CTSM-40R Related Documents

CTSM-40R.ZIP-1631087816940.zip CTSM-40R.PDF-1631087816935.pdf CTSM-40R.DWG-1631087816964.dwg 156.pdf-1631087816941.pdf CTSM-40R.DXF-1631087816943.dxf
