30312R Mersen Fuse Holders

30312R on Advantage Electric Supply
Mersen

Part#:30312R

Alt. Part#:782001759483

Manufacturer:Mersen

Category:Fuse Holders

Product Lifecycle:Active

Only 1 left in stock. Order Now!

Aug 2, 2025

Product description

30312R Mersen - Fuse Block 600VAC 600VDC Class CC 30A 2-Pole Screw with Reinforced Clip

Product Details

  • Number of Poles
    2 Pole
  • Current Rating
    30 A
  • Weight
    104.42 g
  • Voltage
    600 VAC
  • Fuse Type/Class
    Class CC
  • Installation Mounting
    Screw Mount or DIN Rail
  • Rated voltage DC UL
    600 V
  • Product Length
    3.04 in
  • Ampere Rating
    30 A
  • Max Fuse Rating
    30 A
  • Sell Pack Weight
    1.21 lb
  • ROHS Compliant
    Yes
  • Product Width
    0.85 in
  • Fuse Class
    Class CC
  • Body/Insulating Material
    GFPC
  • Sell Pack Width
    3.12 in
  • Number of Poles
    2-pole
  • Rated voltage AC UL
    600 V
  • Product Weight
    0.23 lb
  • Sell Pack Quantity
    5 Each
  • Sell Pack Height
    2.12 in
  • Short Circuit Current Rating (SCCR)
    200
  • Sell Pack Length
    7 in
  • Fuse Installation Method
    Clip-in
  • Product Height
    1.31 in
  • Amps:
    32 A
  • Fuse Type:
    Class CC
  • Series:
    303
  • Fuse Voltage Rating:
    600 Volt AC/DC
  • Approval:
    UL 4248
  • Shipping Height:
    2.00 In.
  • Terminal Type:
    Screw with Double Quick Connect
  • Shipping Length:
    3.00 In.
  • Wire Size:
    14 to 10 AWG (Copper)
  • Shipping Weight:
    0.20 lbs.
  • Fuse Current Rating:
    30 Amp
  • Type:
    Open Style
  • Body Material:
    Glass Filled Polycarbonate
  • Shipping Width:
    2.00 In.
  • Clip Type:
    Tin Plated Copper Alloy
  • UPC:
    782001759483
  • Poles:
    2

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 30312R on Advantage Electric Supply is $44.81. Order now.


About the product

30312R Mersen - Fuse Block 600VAC 600VDC Class CC 30A 2-Pole Screw with Reinforced Clip | Mersen midget fuse blocks accommodate all 30 ampere 1-1/2” x 13/32” midget fuses. Class CC fuse blocks accommodate all 30 ampere Class CC fuses. A choice of box, screw, or pressure-plate connectors fit a wide range of stranded or solid copper wire. Insulators are glassfilled polycarbonate (GFPC) with verified dielectric strength in excess of 2500V. Fuse blocks feature a unique adder block which can be snapped onto 1-, 2- or 3-pole blocks to form multi-pole segmented blocks of as many poles as desired. All fuse clips are made of high conductivity tin-plated copper alloy. | Features: | Application:



This item can ship within 24h!

Manufacturer warranty

30312R Mersen

$44.81

Your price can be lower.
Log in or Create account to check your discount

Stock:

1

Select Qty:

$44.81

$44.81 each

Minimum order quantity for this item is 5.

Fast Shipping & Delivery

We deliver nationwide and international


Secure Payment Processing

with money back guarantee


Warranty On All Parts

Manufacturer warranty


Responsive Customer Support

Let us know how we can help!


Need more details?

Feel free to chat with us

Compare 30312R with other Fuse Holders products

Number of Poles

Current Rating

Weight

Voltage

Fuse Type/Class

Installation Mounting

Rated voltage DC UL

Product Length

Ampere Rating

Max Fuse Rating

Selected product

30312R
1 in stock
30312R
Mersen

30312R Mersen - Fuse Block 600VAC 600VDC Class CC 30A 2-Pole Screw with Reinforced Clip

Number of Poles2 Pole

Current Rating30 A

Weight104.42 g

Voltage600 VAC

Fuse Type/ClassClass CC

Installation MountingScrew Mount or DIN Rail

Rated voltage DC UL600 V

Product Length3.04 in

Ampere Rating30 A

Max Fuse Rating30 A

30313R
1 in stock
30313R
Mersen

30313R Mersen - Fuse Block 600VAC 600VDC Class CC 30A 3-Pole Screw with Reinforced Clip

Number of Poles3 Pole

Current Rating30 A

Weight158.9 g

Voltage600 VAC

Fuse Type/ClassClass CC

Installation Mounting-

Rated voltage DC UL600 V

Product Length-

Ampere Rating30 A

Max Fuse Rating-

30320R
2 in stock
30320R
Mersen

30320R Mersen - Fuse Block 600VAC 600VDC Class CC 30A Adder Pressure Plate with Reinforced Clip

Number of PolesAdder Pole

Current Rating30 A

Weight45.4 g

Voltage600 VAC

Fuse Type/ClassClass CC

Installation Mounting-

Rated voltage DC UL600 V

Product Length-

Ampere Rating30 A

Max Fuse Rating-
