60603J Mersen Fuse Holders
Part#:60603J
Alt. Part#:782001758295
Manufacturer:Mersen
Category:Fuse Holders
Product Lifecycle:Active
Product description
60603J Mersen - Fuse Block 600VAC 600VDC Class J 60A 3-Pole Box
Product Details
- Number of Poles 3 Pole
- Current Rating 60 A
- Weight 308.72 g
- Voltage 600 VAC
- Rated voltage AC UL 600 V
- Body/Insulating Material GFPC
- Product Height 2.12 in
- Sell Pack Length 10.68 in
- Ampere Rating 60 A
- Fuse Installation Method Clip-in
- Sell Pack Weight 3.57 lb
- Rated voltage DC UL 600 V
- Number of Poles 3-pole
- Product Length 4 in
- Sell Pack Height 4.75 in
- Fuse Type/Class Class J
- Max Fuse Rating 60 A
- Sell Pack Quantity 5 Each
- ROHS Compliant Yes
- Product Width 4.65 in
- Product Weight 0.68 lb
- Sell Pack Width 4.81 in
- Fuse Class Class J
- Short Circuit Current Rating (SCCR) 200
- Installation Mounting Direct Screw Mount
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of 60603J on Advantage Electric Supply is $223.31. Order now.
About the product
60603J Mersen - Fuse Block 600VAC 600VDC Class J 60A 3-Pole Box | A choice of screw, pressure plate, box and special order stud connectors fit a wide range of stranded or solid copper or aluminum conductors. Insulators are either molded glass-filled polycarbonate (GFPC) or phenolic with verified dielectric strength in excess of 2500V. 30A, 60A and the new 100A SJ fuse blocks feature a unique adder block configuration which can be snapped onto 1-, 2-, or 3-pole blocks to form multi-pole segmented blocks of as many poles as desired. All fuse clips are made of high conductivity tin-plated copper, with a choice of spring-reinforced or non-spring reinforced clips. Space saving options are now available in the 30A and 100A configurations which are noted in the product selection tables. | Features: *Class J Blocks (600V) use with AJT, A4J, HSJ | Application:
