B1069363 Mersen Electronic Components

Product Details

• Catalogue No.
  8.000.299
• ROHS Compliant
  Yes
• Rated Impulse Withstand Voltage
  12 kV
• Power Dissipation by Ith without Solid Links
  33 W
• Max Power dissipation of Solid Links Pn
  2.6 W
• Sell Pack Weight
  5.335 lb
• Sell Pack Length
  9.76 in
• Frequency
  50...60 Hz
• Fuse Size
  1
• Number of Poles
  3-Pole
• Sell Pack Width
  7.36 in
• Product Weight
  5.335 lb
• Switchability
  1-,2-,3-,4-pole switching
• Rated Insulation Voltage
  1000 V
• Max Power dissipation of Fuse Links Pn
  23 W
• Rated voltage AC IEC
  800 V
• Ampere Rating
  160 A
• Short Circuit Current Rating (SCCR)
  Ue=AC 800 V; Ie=160 A 10kA Ue=AC 800 V; Ie=250 A 10kA
• Rated Duty
  uninterrupted duty
• Degree of Pollution
  3
Product Width
7.28 in
Conventional Free Air thermal Current - Solid Links
400 A
Sell Pack Height
4.41 in
Product Length
4.35 in
Product Height
9.69 in
Sell Pack Quantity
1 EACH
Installation Mounting
Bottom Fitting/panel
Utilization Category
AC21B @ Ue = AC 690 V; Ie = 200 A
Conventional Free Air thermal Current With Fuse-Links Ith
160 A
Comments
Cable termination components : 6 M10 terminal screws
Rated short circuit making capacity with solid links Icm
8.2 kA
Power Dissipation by Ith without Fuse-Links
13 W
Rated SC Withstand
8 kA / 1 s
