C300566 Mersen Fuses
Product Details
- Current Rating 400 A
- Terminal Type DIN Type Blades
- Weight 1120.926 g
- Trip Class High Speed
- Country Of Origin FR,MX
- Fuse Class Semiconductor
- Fuse Size 73
- Indication System Yes
- Product Height 3.09 in
- Catalogue No. PC73UD13C400D1A
- Connection/Terminal Type DIN Type Blades
- Rated voltage AC UL 1300 V
- Product Weight 2.469 lb
- Sell Pack Width 5.91 in
- Clearing I2t At Rated Voltage 205 kA²s
- AC Max I.R./Breaking Capacity: I1 126 kA
- Sell Pack Quantity 3 EACH
- Mounting Bolted
- Body/Insulating Material Ceramic
- Sell Pack Weight 7.408 lb
- Melting I2t 25 kA²s
- Connection/Terminal Material Silver-Plated Copper
- Product Length 5.25 in
- Speed/Characteristic aR
- Rated voltage AC IEC 1250 V
- Power Dissipation at Rated Current Value 93 W
- Product Width 2.87 in
- Ampere Rating 400 A
- Indication System Type Striker
- Sell Pack Length 9.84 in
- Sell Pack Height 3.54 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of C300566 on Advantage Electric Supply is $1,261.37. Order now.
About the product
C300566 Mersen - Square Body High-Speed Fuse Protistor® Size 73 aR 1250VAC IEC 1300VAC UL 400A With Striker DIN 110 Blades
Product type: Semiconductor Protection Fuses
These 1250/1300V Protistor® fuse-links provide maximum flexibility in equipment design and ultimate protection for today's power conversion equipment. These aR ultra-fast acting square body fuse-links are available in different body sizes, each size having multiple worldwide acceptable mounting styles.
The Protistor® have been engineered to provide state-of-the-art protection for semiconductors: diodes, thyristors and IGBT devices. Fuses are assembled with die-cut elements embedded in solidified sand, which helps control arcing characteristics for a lower I²t and high interrupting rating level. All contact surfaces are silver plated and all hardware is non-magnetic.
All fuse-links can be equipped with a low voltage trip-indicator which can operate a field mountable microswitch.
*Multiple body sizes and terminals or blades combination
*aR Class according to IEC 60269-4 and VDE 636-23
*Very low I²t for improved semiconductor protection
*Ultra fast acting
*Current limiting
*Superior cycling capability
