CEP-FSPDB250 Mersen Fuse Holders
Part#:CEP-FSPDB250
Alt. Part#:782001499068
Manufacturer:Mersen
Category:Fuse Holders
Product Lifecycle:Active
Product description
CEP-FSPDB250 Mersen Compact PDB 600V 205A - 250A Tin-plated Aluminum 1-Pole 2 - 4 + 3 + 3 openings; 250 - #6 --- #6-#14 + #4-#14 + #2-#14
Product Details
- Number of Poles 1 Pole
- Current Rating 250 A
- Weight 258.78 g
- Voltage 600 V
- Short Circuit Rating (Standalone) 10 kA
- Short Circuit Rating (Class J) 450 A
- Number of Poles 1-Pole
- Number of Openings per Pole (Secondary) 4 + 3 + 3
- Installation Mounting Screw Mount or DIN Rail
- Short Circuit Rating (Class RK1) 400 A
- Rated voltage AC UL 600 V
- Hex/Screw Size & Type (Primary) hex 1/4
- Wire Range (Secondary) #6-#14 + #4-#14 + #2-#14
- Sell Pack Quantity 3 Each
- Ampere Rating (CU) 250 A
- Body/Insulating Material Glass Filled Polycarbonate
- Torque Rating (Secondary) #6 50; #8-#14 35; #4-#14 50; #2 140; #4-#14 50
- Product Length 3.74 in
- ROHS Compliant Yes
- Connector Material Tin-plated Aluminum
- Hole Diameter (Primary) 0.45 in
- Product Weight 0.57 lb
- Sell Pack Height 2.5 in
- Short Circuit Rating (Class CC) 30 A
- Short Circuit Rating (Class RK5) 200 A
- Hex/Screw Size & Type (Secondary) hex 1/8 + hex 1/8 + hex 5/32
- Product Width 2.03 in
- Sell Pack Length 9.5 in
- Rated voltage DC UL 600 V
- Number of Openings per Pole (Primary) 2
- Hole Diameter (Secondary) NaN in
- Wire Range (Primary) DLO 4/0 - #6
- Sell Pack Weight 2 lb
- Ampere Rating (AL) 205 A
- Short Circuit Rating (Class T) 450 A
- Connector Type (Primary) Box
- Torque Rating (Primary) 250 250; 3/0-2/0 200; 1/0-#6 150
- Product Height 2.46 in
- Short Circuit Rating (Class G) 60 A
- Connector Type (Secondary) Box
- Wire Range (Primary) 250 - #6
- Sell Pack Width 4.5 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
CEP-FSPDB250 Mersen Compact PDB 600V 205A - 250A Tin-plated Aluminum 1-Pole 2 - 4 + 3 + 3 openings; 250 - #6 --- #6-#14 + #4-#14 + #2-#14 | Mersen's finger safe IP20-rated Power Distribution Blocks are part of the new Compact EP® line of products. The compact footprint allows space savings in panels, contributing to reduced panel size when compared to traditional power distribution blocks.
The Compact PDB is ideal for low voltage applications. Rated for UL-600V, ampere range of 85-250A, it can accommodate wire ranges AWG 18-3/0, catering to a wide range of low voltage applications. The PDBs
can be DIN rail mounted, are dual wire rated, and are capable of DLO wire acceptance allowing ease of installation. Translucent covers allow visual inspection of wire termination points and wiring configurations. | *Finger-safe protection: Fully insulated block ensures touch-safe isolation of live parts. Recessed termination screws and wire openings provide IP20 grade protection and qualify as “fingersafe” per IEC 529
*Translucent cover allows for visual inspection of wire termination
*Compact modularity: Smaller footprint allows panel builders to reduce space and build smaller or higher density panels
*Snap on DIN-rail mounting: Integral DIN rail adaptors allow for quick and easy installations on 35mm DIN rail, yielding lower installed costs
*Captive termination screws: Unique channel design ensures captive metric wire termination screws. Screws can never be lost
*Multiple wire ratings: Blocks are multi wire rated - see multi wire rating table and can accommodate 18AWG wire for low voltage applications such as LED lighting
*Can also accept DLO wires.
