D1069365 Mersen Electronic Components

Product Details

• Ampere Rating
  160 A
• Frequency
  50...60 Hz
• Fuse Size
  1
• Max Power dissipation of Fuse Links Pn
  23 W
• Product Width
  7.28 in
• Switchability
  1-,2-,3-,4-pole switching
• Rated Impulse Withstand Voltage
  12 kV
• Conventional Free Air thermal Current With Fuse-Links Ith
  160 A
• Product Weight
  5.335 lb
• Sell Pack Weight
  5.335 lb
• Catalogue No.
  8.002.562
• Product Length
  4.35 in
• Sell Pack Height
  4.41 in
• Rated short circuit making capacity with solid links Icm
  8.2 kA
• Utilization Category
  AC22B @ Ue = AC 500 V; Ie = 250 A
• Number of Poles
  3-Pole
• Max Power dissipation of Solid Links Pn
  2.6 W
• Rated voltage AC IEC
  800 V
• Comments
  6 clamp straps 70-150 mm²
• Short Circuit Current Rating (SCCR)
  Ue=AC 800 V; Ie=160 A 10kA Ue=AC 800 V; Ie=250 A 10kA
Rated Insulation Voltage
1000 V
Sell Pack Length
9.76 in
ROHS Compliant
Yes
Rated SC Withstand
8 kA / 1 s
Power Dissipation by Ith without Solid Links
33 W
Sell Pack Width
7.36 in
Degree of Pollution
3
Installation Mounting
Bottom Fitting/panel
Product Height
9.69 in
Rated Duty
uninterrupted duty
Conventional Free Air thermal Current - Solid Links
400 A
Power Dissipation by Ith without Fuse-Links
13 W
Sell Pack Quantity
1 EACH
