J1032961 Mersen Fuses
Product Details
- Current Rating 25 A
- Terminal Type Cylindrical
- Weight 6.173 lb
- Voltage 36 kV AC
- Country Of Origin HU
- Fuse Class High Voltage IEC Fuses
- Ampere Rating 25 A
- Body/Insulating Material Ceramic
- Sell Pack Width 4.33 in
- Catalogue No. 45DB360V25PTS
- Clearing I2t At Rated Voltage 6500 A²s
- Sell Pack Quantity 1 EACH
- AC Max I.R./Breaking Capacity: I1 32 kA
- Mounting Clip
- Sell Pack Length 25.59 in
- Power Dissipation at Rated Current Value 100 W
- Fuse Size d=56mm, L=537mm
- Product Length 23.74 in
- Min Interrupting Rating (MBC) 110 A
- Connection/Terminal Type Cylindrical
- Sell Pack Height 3.94 in
- Indication System Type Striker
- Product Diameter 2.2 in
- Rated voltage AC IEC 36 kV
- Product Weight 6.173 lb
- Sell Pack Weight 6.173 lb
- Indication System Yes
- Connection/Terminal Material Silver-Plated Copper
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
J1032961 Mersen - High Voltage DIN Back-up fuse for Transformer Limitor® VDE T402 36kVAC IEC 25A d56mm, L537mm With Thermal Striker 80N Low power losses
Mersen HV fuse-links have been used for reliable protection in high-voltage switchgear and controlgear and high-voltage systems for decades.
For the Limitor®-PTS range, Mersen innovates with new fuse-element designs to reduce power losses and new thermal striker to prevent overheating in the fuse compartment of the switch gear.
Mersen uses the best materials : fuse-elements are in pure silver, caps are in copper coated with silver and body is in ceramic.
Limitor®-PTS HV fuse-links are dedicated to protect transformers in combination with air or gas insulated switchgear against the thermal and dynamic effects of short-circuits.
Siemens and Ormazabal recommend Limitor®-PTS HV fuses to be used in their gas-insulated switchgear.
Low switching voltage
*Large current ratings range
*Very low power losses
*Energy efficency
*New thermal striker patented by Mersen to prevent overheating
*Medium striker 80N / 30mm
*New cap design for a better compatibility with all types of clips and easier assembly
*Outdoor and indoor use
*Coordination with IEC 60787, IEC 62271-105 and VDE 0670 T303
Best used in SF6 insulated switch gear and compact switch gear
*HV Transformer protection
