N076073 Mersen Fuses
Product Details
- Current Rating 375 A
- Terminal Type DIN Type Blades
- Weight 1801.472 g
- Trip Class High Speed
- Country Of Origin FR
- Fuse Class Semiconductor
- Speed/Characteristic aR
- Connection/Terminal Type DIN Type Blades
- Product Weight 3.968 lb
- Sell Pack Length 10.43 in
- Catalogue No. PC93UG15C375D4F
- Connection/Terminal Material Silver-Plated Copper
- Indication System Yes
- Product Height 3.37 in
- Mounting Bolted
- Fuse Size 93
- Design Details URG
- Product Length 6.54 in
- Sell Pack Quantity 1 EACH
- Clearing I2t At Rated Voltage 185 kA²s
- Indication System Type Striker
- Body/Insulating Material Ceramic
- Sell Pack Weight 3.968 lb
- Rated voltage AC IEC 1500 V
- AC Max I.R./Breaking Capacity: I1 200 kA
- Product Width 2.93 in
- Sell Pack Height 3.74 in
- Ampere Rating 375 A
- Power Dissipation at Rated Current Value 130 W
- Sell Pack Width 4.92 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of N076073 on Advantage Electric Supply is $4,405.57. Order now.
About the product
N076073 Mersen - High performance square body fuse-link Protistor® Size 93 aR 1500VAC IEC 375A With Striker DIN 140 Blades
Product type: Semiconductor Protection Fuses
Mersen 1500 V PSC fuse-links provide maximum flexibility in equipment design and ultimate protection for today’s power conversion equipment. These square body fuse-links are available in three different body sizes, each size having four worldwide acceptable mounting styles. The different mounting styles and body sizes along with a broad range of ampere ratings allow greatest flexibility in equipment design.
The Mersen PSC fuses have been engineered to provide state-of-the-art protection for SCR’s, diodes, thyristors, GTO’s and IGBT devices. They have pure silver die-cut elements embedded in solidified sand which helps control arcing characteristics for low I²t and high breaking capacity. All contact surfaces are silver plated and all hardware is non-magnetic.
All fuse links are equipped with a low voltage trip-indicator. This trip-indicator can operate a field mountable microswitch which is easily mounted directly on to the fuse even while in service.
*Extremely fast acting
*Current limiting
*Very low l²t
*Worldwide acceptability
*Superior cycling ability
*Choice of mounting styles
*Broad range of ampere rating
