S1023056 Mersen Electronic Components

Product Details

• Frequency
  50...60 Hz
• Rated Duty
  uninterrupted duty
• Max Power dissipation of Fuse Links Pn
  23 W
• Product Width
  2.8 in
• Sell Pack Length
  9.69 in
• Rated Impulse Withstand Voltage
  12 kV
• Power Dissipation by Ith without Solid Links
  10 W
• Product Height
  9.69 in
• Rated voltage AC IEC
  690 V
• Rated SC Withstand
  8 kA / 1 s
• Comments
  Cable termination components : 2 M10 terminal screws
• Product Length
  4.35 in
• Degree of Pollution
  3
• Utilization Category
  AC22B @ Ue = AC 500 V; Ie = 250 A
• Short Circuit Current Rating (SCCR)
  80kA@Ue=AC 400 V;Ie=250 A / 80kA@Ue=AC 500 V;Ie=250 A / 80kA (1-,2-pole)@Ue=AC 690 V;Ie=200 A / 50kA (3-,4-pole)@Ue=AC 690 V;Ie=200 A
• Rated Insulation Voltage
  1000 V
• Installation Mounting
  Bottom Fitting/panel
• Sell Pack Quantity
  1 EACH
• Design Details
  for direct installation on to bus bars with M10 screws
• Conventional Free Air thermal Current With Fuse-Links Ith
  250 A
Sell Pack Height
4.41 in
Switchability
1-,2-,3-,4-pole switching
ROHS Compliant
Yes
Max Power dissipation of Solid Links Pn
2.6 W
Sell Pack Width
3.11 in
Product Weight
2.006 lb
Catalogue No.
1.001.818
Fuse Size
1
Ampere Rating
250 A
Power Dissipation by Ith without Fuse-Links
4 W
Rated short circuit making capacity with solid links Icm
8.2 kA
Conventional Free Air thermal Current - Solid Links
400 A
Sell Pack Weight
2.006 lb
Number of Poles
1-Pole
