TR150R Mersen Fuses

Mersen TR150R TR150R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 250VDC 150A Blade Tri-Onic®
Mersen

Part#:TR150R

Manufacturer:Mersen

Alt. Part#:782001748067

Product Lifecycle:Active

Get a quick Quote!

TR150R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 250VDC 150A Blade Tri-Onic®

About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the TR150R Mersen price in the box on the right side or send a quick quote.

Product Details

  • Current Rating
    150 A
  • Terminal Type
    Blade
  • Material
    PolyTube
  • Type
    Low Voltage UL/CSA Fuses
  • Weight
    341.032 g
  • Voltage
    250 VAC / 250 VDC
  • Approvals
    *UL listed to standard 248-12 File E2137 *CSA certified to standard C22.2 no. 248.12 *DC listed to UL standard 248 TRS only
  • UL Certification
    YES
  • Trip Class
    Time Delay
  • Fuse Class
    Class RK5
  • Series:
    TR-R
  • Terminal Type:
    Blade
  • Volts:
    250 VAC/DC
  • Type:
    Class RK5
  • Time Delay:
    Voltage Rating
  • Length:
    7-1/8 Inch
  • Diameter:
    1-9/16 Inch
  • Interrupting Rating:
    200 Kiloamp (AC)
  • Approval:
    UL 248-12
  • Amps:
    150 A
  • Characteristics:
    Time Delay
  • Shipping Width:
    2.00 In.
  • Shipping Length:
    8.00 In.
  • Shipping Weight:
    0.90 lbs.
  • Shipping Height:
    2.00 In.
  • UPC:
    782001748067
  • Sell Pack Width
    1.56 in
  • Sell Pack Quantity
    1 Each
  • Sell Pack Height
    7.31 in
  • Sell Pack Length
    1.56 in
  • Sell Pack Weight
    0.95 lb
  • Product Length
    7.13 in
  • Body/Insulating Material
    PolyTube
  • Product Diameter
    1.56 in
  • Connection/Terminal Type
    Blade
  • Product Weight
    0.9 lb
  • AC Max I.R./Breaking Capacity: I1
    200 kA
  • Ampere Rating
    150 A
  • Mounting
    Clip
  • Connection/Terminal Material
    Tin-Plated Copper
  • Rated voltage AC UL
    250 V
  • Frequency
    50/60 Hz
  • Rated voltage DC UL
    250 V
  • ROHS Compliant
    Yes
  • Speed/Characteristic
    Time Delay
  • Fuse Class
    Class RK5

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


TR150R Description

TR150R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 250VDC 150A Blade Tri-Onic®
