TR45R Mersen Fuses

Mersen TR45R TR45R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 250VDC 45A Ferrule Tri-Onic®
Mersen

Part#:TR45R

Manufacturer:Mersen

Alt. Part#:782001747923

Product Lifecycle:Active

Get a quick Quote!

TR45R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 250VDC 45A Ferrule Tri-Onic®

About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the TR45R Mersen price in the box on the right side or send a quick quote.

Product Details

  • Current Rating
    45 A
  • Terminal Type
    Ferrule
  • Material
    PolyTube
  • Type
    Low Voltage UL/CSA Fuses
  • Weight
    53.9665 g
  • Voltage
    250 VAC / 250 VDC
  • Approvals
    *UL listed to standard 248-12 File E2137 *CSA certified to standard C22.2 no. 248.12 *DC listed to UL standard 248 TRS only
  • UL Certification
    YES
  • Trip Class
    Time Delay
  • Fuse Class
    Class RK5
  • UPC:
    78200174792
  • Shipping Weight:
    1.20 lbs.
  • Shipping Length:
    5.00 In.
  • Shipping Width:
    4.00 In.
  • Shipping Height:
    2.00 In.
  • Sell Pack Height
    1.69 in
  • Sell Pack Length
    4.25 in
  • Sell Pack Width
    3.12 in
  • Sell Pack Weight
    1.42 lb
  • Sell Pack Quantity
    10 Each
  • Product Length
    3 in
  • Product Diameter
    0.81 in
  • Connection/Terminal Type
    Ferrule
  • Product Weight
    0.135 lb
  • Body/Insulating Material
    PolyTube
  • Connection/Terminal Material
    Copper
  • Ampere Rating
    45 A
  • ROHS Compliant
    Yes
  • Frequency
    50/60 Hz
  • Fuse Class
    Class RK5
  • Mounting
    Clip
  • Speed/Characteristic
    Time Delay
  • AC Max I.R./Breaking Capacity: I1
    200 kA
  • Rated voltage DC UL
    250 V
  • Rated voltage AC UL
    250 V

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


TR45R Description

TR45R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 250VDC 45A Ferrule Tri-Onic®
