TR6-1/4R Mersen Fuses

Mersen TR6-1/4R TR6-1/4R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 160VDC 6.25A Ferrule Tri-Onic®
Mersen

Part#:TR6-1/4R

Manufacturer:Mersen

Alt. Part#:782001747763

Product Lifecycle:Active

Get a quick Quote!

TR6-1/4R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 160VDC 6.25A Ferrule Tri-Onic®

About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the TR6-1/4R Mersen price in the box on the right side or send a quick quote.

Product Details

  • Current Rating
    6.25 A
  • Terminal Type
    Ferrule
  • Material
    PolyTube
  • Type
    Low Voltage UL/CSA Fuses
  • Weight
    16.7795 g
  • Voltage
    250 VAC / 160 VDC
  • Approvals
    *UL listed to standard 248-12 File E2137 *CSA certified to standard C22.2 no. 248.12 *DC listed to UL standard 248 TRS only
  • UL Certification
    YES
  • Trip Class
    Time Delay
  • Fuse Class
    Class RK5
  • Approval:
    UL 248-12
  • Type:
    Class RK5
  • Time Delay:
    Voltage Rating
  • Length:
    2 Inch
  • Characteristics:
    Time Delay
  • Diameter:
    9/16 Inch
  • Terminal Type:
    Ferrule
  • Interrupting Rating:
    200 kA (AC)
  • Amps:
    32 A
  • Volts:
    250 VAC
  • Shipping Weight:
    0.40 lbs.
  • Shipping Length:
    3.00 In.
  • UPC:
    782001747763
  • Shipping Width:
    2.00 In.
  • Series:
    TR-R
  • Shipping Height:
    1.00 In.
  • Sell Pack Height
    1.19 in
  • Sell Pack Width
    2.06 in
  • Sell Pack Quantity
    10 Each
  • Sell Pack Length
    3 in
  • Sell Pack Weight
    0.53 lb
  • Product Length
    2 in
  • Product Diameter
    0.56 in
  • Product Weight
    0.05 lb
  • Body/Insulating Material
    PolyTube
  • Connection/Terminal Type
    Ferrule
  • Connection/Terminal Material
    Copper
  • AC Max I.R./Breaking Capacity: I1
    200 kA
  • Frequency
    50/60 Hz
  • Rated voltage DC UL
    160 V
  • Ampere Rating
    6.25 A
  • Rated voltage AC UL
    250 V
  • Mounting
    Clip
  • ROHS Compliant
    Yes
  • Fuse Class
    Class RK5
  • Speed/Characteristic
    Time Delay

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


TR6-1/4R Description

TR6-1/4R Mersen - Fuse TR-R - Class RK5 - Time-Delay 250VAC 160VDC 6.25A Ferrule Tri-Onic®
