V089488 Mersen Fuses

Mersen V089488 V089488 Mersen - High-Speed Cylindrical Fuse Protistor® Size 20x127 gR (gRB) 1000VDC IEC 25A
Mersen

Part#:V089488

Manufacturer:Mersen

Alt. Part#:3605340083491

Product Lifecycle:Active

Get a quick Quote!

V089488 Mersen - High-Speed Cylindrical Fuse Protistor® Size 20x127 gR (gRB) 1000VDC IEC 25A

About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at Advantage Electric Supply site. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.

Check out the V089488 Mersen price in the box on the right side or send a quick quote.

Product Details

  • Current Rating
    25 A
  • Terminal Type
    Ferrule
  • Weight
    99.88 g
  • UL Certification
    YES
  • Trip Class
    High Speed
  • Country Of Origin
    FR
  • Fuse Class
    Semiconductor
  • Sell Pack Height
    1.18 in
  • Sell Pack Width
    5.51 in
  • Sell Pack Length
    10.63 in
  • Sell Pack Weight
    2.205 lb
  • Sell Pack Quantity
    10 EACH
  • Product Length
    5 in
  • Product Diameter
    0.81 in
  • Product Weight
    0.22 lb
  • Body/Insulating Material
    Ceramic
  • Connection/Terminal Type
    Ferrule
  • Connection/Terminal Material
    Silver-Plated Copper
  • Power Dissipation at Rated Current Value
    9 W
  • Mounting
    Clip
  • Max. Rated Breaking Capacity DC
    100kA
  • Fuse Size
    20x127
  • Rated voltage DC IEC
    1000 V
  • Speed/Characteristic
    gR
  • Ampere Rating
    25 A
  • Catalogue No.
    FD20GB100V25

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.


V089488 Description

V089488 Mersen - High-Speed Cylindrical Fuse Protistor® Size 20x127 gR (gRB) 1000VDC IEC 25A

Product type: Semiconductor Protection Fuses

Specially developed for DC applications, 20x127 gR cylindrical is a fast acting, full range fuse used in the protection of auxiliaries, control circuit and other measuring and monitoring devices.

*International 20x127mm (13/16" x 5") for worldwide acceptance

*gR Class according to VDE 636-23 and IEC 60269-4

*Low I²t for improved semiconductor protection

*Eliminate all overloads

*Extremely fast acting

*Current limiting

*Excellent cycling capability



Manufacturer warranty
