V1023219 Mersen Electronic Components

Product Details

• Switchability
  1 x triple pole, 3 x single pole
• Rated SC Withstand
  8 kA / 1 s
• Max Power dissipation of Solid Links Pn
  9 W
• Sell Pack Height
  7.68 in
• Fuse Size
  2
• Utilization Category
  AC23B @ Ue = AC 400 V; Ie = 400 A
• Rated Insulation Voltage
  1000 V
• Product Weight
  9.987 lb
• Rated voltage AC IEC
  690 V
• ROHS Compliant
  Yes
• Rated Duty
  uninterrupted duty
• Installation Mounting
  Bus bar system 185 mm
• Sell Pack Width
  3.94 in
• Ampere Rating
  400 A
• Rated Impulse Withstand Voltage
  12 kV
• Power Dissipation by Ith without Solid Links
  151 W
• Product Height
  26.97 in
• Short Circuit Current Rating (SCCR)
  120kA@Ue = AC 400 V; Ie = 400 A / 120kA@Ue = AC 500 V; Ie = 400 A / 120kA@Ue = AC 690 V; Ie = 315 A / 100kA@Ue = AC 690 V; Ie = 400 A
• Rated short circuit making capacity with solid links Icm
  16 kA
• Conventional Free Air thermal Current With Fuse-Links Ith
  400 A
Sell Pack Quantity
1 EACH
Design Details
MULTIVERT® with lateral bus bar terminals bus bar coupler switch cable terminal connection to right or left side possible
Power Dissipation by Ith without Fuse-Links
61 W
Product Width
3.86 in
Sell Pack Weight
9.987 lb
Product Length
7.48 in
Number of Poles
3-Pole
Conventional Free Air thermal Current - Solid Links
630 A
Max Power dissipation of Fuse Links Pn
34 W
Catalogue No.
1.280.000
Comments
Cable termination components : M12 bus bar terminal
Sell Pack Length
27.09 in
Degree of Pollution
3
Frequency
50...60 Hz
