V302100 Mersen Fuses
Product Details
- Current Rating 630 A
- Terminal Type End Contact with Threaded Holes
- Weight 1105.944 g
- Trip Class High Speed
- Country Of Origin FR
- Fuse Class Semiconductor
- Melting I2t 101610 A²s
- Catalogue No. D73GB55V630TF
- Indication System Yes
- Body/Insulating Material Ceramic
- Product Length 2.91 in
- Sell Pack Width 4.33 in
- Sell Pack Quantity 1 EACH
- Rated voltage DC IEC 550 V
- Product Width 2.87 in
- Sell Pack Height 3.15 in
- Fuse Size 73
- Product Weight 2.436 lb
- Sell Pack Length 5.12 in
- Rated voltage DC UL 600 V
- Indication System Type Striker
- Mounting Bolted
- Power Dissipation at Rated Current Value 89 W
- Product Height 3.09 in
- Speed/Characteristic gR
- Connection/Terminal Material Silver-Plated Brass
- Ampere Rating 630 A
- Connection/Terminal Type End Contact with Threaded Holes
- Sell Pack Weight 2.436 lb
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of V302100 on Advantage Electric Supply is $2,623.75. Order now.
About the product
V302100 Mersen - Square Body High-Speed Fuse Protistor® Size 73 gR 550VDC IEC 600VDC UL 630A With Striker Flush ends metric threads
Product type: Semiconductor Protection Fuses
These Protistor® fuse-links provide maximum flexibility in equipment design and ultimate protection for today's power conversion equipment. These square body fuse-links are available in different body sizes, each size having multiple worldwide acceptable mounting styles.
The Protistor® have been engineered to provide state-of-the-art protection for semiconductors: diodes, thyristors, GTO's and IGBT devices. Fuses are assembled with pure silver, die-cut elements embedded in solidified sand, which helps control arcing characteristics for a lower I²t and high interrupting rating level. All contact surfaces are silver plated and all hardware is non-magnetic.
All fuse-links can be equipped with a low voltage trip-indicator which can operate a field mountable microswitch.
*Multiple body sizes and terminals or blades combination
*gR Class according to IEC 60269-4 and VDE 636-23
*Low I²t for improved semiconductor protection
*Extremely fast acting
*Eliminate all overloads
*Excellent cycling capability
