X331151 Mersen Fuse Holders
Part#:X331151
Alt. Part#:0782001311049
Manufacturer:Mersen
Category:Fuse Holders
Product Lifecycle:Active
Product description
X331151 Mersen - Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 3-Pole+N Pressure Plate IP20
Product Details
- Number of Poles 3+N Pole
- Current Rating 50 A
- Weight 600.642 g
- Voltage 800 VAC
- Ampere Rating 50
- Number of Poles 3-Pole+N
- Rated Impulse Withstand Voltage 8
- Sell Pack Height 3.35 in
- ROHS Compliant Yes
- Body/Insulating Material Polyamide
- Comments Wiring tool : PZ2 or flat 5.5x1mm screw drivers recommended (max. diameter 6mm)
- Product Height 4.36 in
- Rated voltage DC IEC 750 V
- Connection/Terminal Material Tin-Plated Copper
- Conventional Free Air thermal Current With Fuse-Links Ith 50 A
- Sell Pack Weight 1.323 lb
- Short Circuit Current Rating (SCCR) 100 kA
- Fuse Size 14x51
- Torque Rating 30.98 lb-in
- Sell Pack Width 4.72 in
- Frequency 50...60 Hz
- Wiring range #2 - #14
- Fuse Installation Method Clip-in
- Product Width 4.17 in
- Rated voltage AC UL 800 V
- Catalogue No. US143N
- Connection/Terminal Type Clip
- Product Weight 1.323 lb
- Product Length 3.01 in
- Rated voltage DC UL 1000 V
- Max Fuse Rating 50 A
- Installation Mounting DIN rail acc. EN 60715
- Sell Pack Length 7.09 in
- Rated voltage AC IEC 750 V
- Design Details US14 triple pole + neutral conductor
- Rated Insulation Voltage 690 V
- Sell Pack Quantity 1 EACH
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of X331151 on Advantage Electric Supply is $481.01. Order now.
About the product
X331151 Mersen - Fuse Holder UltraSafe™ 800VAC 1000VDC UL Fuse size 14x51 3-Pole+N Pressure Plate IP20 | The innovative and comprehensive UltraSafe™ range of Mersen fuse-holders.
Modular fuse-holders are finger-safe under IEC standards to an IP20 grade of protection, including fuse changing (with the flick of a finger). Modular fuse-holders are available in 1, 2, 3 or 4 poles, with or without visual blown fuse indicator, in UL + IEC version.
Multi-pole units can also be field assembled by ordering pin-ties assembly kit. In this size, the range also offers the possibility to use microswitches (supplied with the holders or ordered separately) to allow remote indication.
UltraSafe™ range is made of tough and durable thermoplastic or thermoset material. | Features: *Finger safe
*Degree of protection: IP20
*Optional visual blown fuse indicator & microswitch
*DIN rail mounting
*Modular design
*Lockable
*Multi-pole assembly kit available
*Sealable in closed and open position
*Plastic material UL94V2 mini
*Flame retardant materials with glow wire flammability index to 960°C | Application: *All circuits up to 750VAC for protection of motors,
*transformers, low voltage distribution, control circuits
*Non-load operation
