Y1000153 Mersen Fuses
Product Details
- Current Rating 16 A
- Terminal Type Cylindrical
- Weight 5.071 lb
- Voltage 12 kV AC
- Country Of Origin HU
- Fuse Class High Voltage IEC Fuses
- Sell Pack Length 15.35 in
- Sell Pack Weight 5.071 lb
- Sell Pack Width 3.15 in
- Sell Pack Quantity 1 EACH
- Sell Pack Height 3.15 in
- Product Length 14.09 in
- Product Diameter 2.56 in
- Body/Insulating Material Ceramic
- Product Weight 5.071 lb
- Connection/Terminal Type Cylindrical
- Indication System Yes
- Connection/Terminal Material Silver-Plated Copper
- AC Max I.R./Breaking Capacity: I1 40 kA
- Indication System Type Striker
- Power Dissipation at Rated Current Value 10 W
- Fuse Size d=65mm, L=292mm
- Min Interrupting Rating (MBC) 0
- Clearing I2t At Rated Voltage 14 kA²s
- Rated voltage AC IEC 12 kV
- Ampere Rating 16 A
- Mounting Clip
- Catalogue No. 45DG120V16P
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
About the product
Y1000153 Mersen - High Voltage DIN General Purpose fuse for Transformer Limitor® 12kVAC IEC 16A d65mm, L292mm With Striker 80N
Mersen HV fuse-links have been used for reliable protection in high-voltage switchgear and controlgear and high-voltage systems for decades.
Limitor®-G HV fuses are general purpose fuses as defined in the IEC 60282-1 standard and dedicated to protect transformers against effects of short-circuit currents and low overcurrents.
To guarantee high quality, Mersen uses the best materials: fuse-elements are in pure silver, caps are in copper coated with silver and bodies are in ceramic.
High breaking capacity
*High current limitation
*Low switching voltage
*Quick breaking
*Non-ageing
*Energy efficency
*New cap design for a better compatibility with all types of clips
*and easier assembly
*Coordination with IEC 60787, IEC 62271-105 and VDE 0670 T303
HV Transformer protection
