Y223006 Mersen Fuse Holders
Part#:Y223006
Alt. Part#:8430399002569
Manufacturer:Mersen
Category:Fuse Holders
Product Lifecycle:Active
Product description
Y223006 Mersen - NH plastic base Size NH1 1000VAC 1000VDC 250A 3-Pole Screw Connection Screw PP Type
Product Details
- Number of Poles 3 Pole
- Current Rating 250 A
- Weight 1501.378 g
- Design Details Type PP (clip contacts)
- Catalogue No. BB13PP
- Torque Rating 283.22 lb-in
- Product Height 8.23 in
- Sell Pack Weight 3.307 lb
- Fuse Size NH1
- Rated voltage DC IEC 440 V
- Product Weight 3.307 lb
- Product Length 2.8 in
- Sell Pack Width 7.87 in
- Sell Pack Length 10.63 in
- Ampere Rating 250 A
- ROHS Compliant Yes
- Rated voltage AC IEC 690 V
- Number of Poles 3-Pole
- Installation Mounting Screw
- Power Acceptance 32 W
- Product Width 7.52 in
- Sell Pack Quantity 1 EACH
- Sell Pack Height 3.94 in
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of Y223006 on Advantage Electric Supply is $731.73. Order now.
About the product
Y223006 Mersen - NH plastic base Size NH1 1000VAC 1000VDC 250A 3-Pole Screw Connection Screw PP Type | NH fuse-bases are available for delivery in single-pole and three-pole designs and can be closely mounted in parallel rows. Each three-pole base is upplied with two phase-partition walls. NH fuse-links plugon covers which clip onto the contact springs can also be supplied for these bases.
Plastic fuse-bases sizes 00 to 3 have a single-part plastic base while size 4 has a metal baseplate with 2 ceramic bases.
The stable silver-plated contact springs are made of electrolytic copper and formed from one piece. Separate springing is provided by highly resilient captive steel springs, making the contact invulnerable to high thermal stress. Size 4 NH fuse-bases are designed for size 4 fuse-links with 8 mm contact blades.
A microswitch (250VAC/10A, terminal size 6.3x0.8mm) can be used with NH fuse-links with striker, it operates when fuse melts or where there is no fuse-link.
Indirect touch protection fuse bases: no microswitch possible.
Rated impulse withstand voltage Uimp: 6kV / 8kV (sizes 00 / 0-4) | Features: *Polyamide insulating bases
*Silver-plated contacts
*High-pressure spring contacts
*Screw or rail mounting
*Connecting cable: 50mm
*Multipolar bases possible by direct linkage in 00 size and with separator accessory in sizes 0, 1, 2 and 3
*Variety of options for protecting active parts through use of accessories: separating plates, separator, cover shields and fuse cover
*Dual cable-connection system on 00 size: by screw or clamp | Application: *For fuse-links with rated voltages up to 1000VAC and 1000VDC
