PILZ-505223 Pilz Safety Switches

Out if stock but available for backorder.

We're dedicated to getting your orders to you as fast as possible and offer different shipping options to make sure you get what you need on time.

We're fully committed to delivering quality you can trust. If something isn't quite right, you have 30 days to return it. And should a part be defective, our 1-year warranty ensures you're covered.

Pilz PILZ-505223 is a non-contact door switch designed for safety applications, featuring a complete magnetic safety switch mechanism. It operates within an ambient air temperature range of -10 to +55°C and is designed for act series connection suitable for electronic/electromechanical relay systems. This switch has a 30mm diameter, supports a rated current of 0.5A for safety-contact maximum current, and utilizes a 4-pin M8 male connector for connections. The dimensions of this part are W30mm x H30mm x L42.7mm, and it offers a degree of protection rated at IP65 and IP67, making it suitable for various environmental conditions. The switch comes in a cylindrical threaded/barrel shape (M30) with a round actuator, constructed with a PBT housing for durability. It operates at a rated voltage of 24Vdc and features a yellow housing. The sensing distance ranges from 8mm (Sao) to 26mm (Sar), and it includes 2 Normally Open (NO) auxiliary contacts without any Normally Closed (NC) auxiliary contacts. The contacts type is 2NO (safety contact; reed), ensuring the switch's functionality in safety circuits.
