LD4006P0 Red Lion Industrial Automation Components
Part#:LD4006P0
Manufacturer:Red Lion
Category:Industrial Automation Components
Product Lifecycle:Active
Product description
Red Lion LD4006P0 is a dual digital counter/rate device from the LD series, featuring built-in batch counting capability. It supports RS-232 and RS-485 communication protocols, accommodating a wide range of supply voltages including 21.6-250Vdc and 50-250Vac. This counter is designed for surface mounting and offers a degree of protection rated at IP65 NEMA 4X. It is equipped with two digital inputs for high-speed counters (20kHz max.; Sink/Source) labeled INPUTS A / B, one digital input for Sink/Source functions labeled RESET / USER INPUT, and one digital output for indicating when a setpoint is reached.
Product Details
- Communication protocol RS-232 RS-485
- Supply voltage (AC) 50-250Vac (48Vac / 100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
- Digital inputs 2 x digital inputs (high-speed counters; 20kHz max.; Sink/Source) (INPUTS A / B) 1 x digital input (Sink/Source) (RESET / USER INPUT)
- Product series / family name Process indicators
- Display 1 row x 6-digits red characters (101mm / 4" high) LED display
- Mounting mode Surface
- Compliant with standard(s) CE EN 61010-1 EN 61010-2-030 RoHS compliant
- Main function Counter (Digital)
- Supply voltage (DC) 21.6-250Vdc (24Vdc / 48Vdc / 60Vdc / 72Vdc / 100Vdc / 110Vdc / 120Vdc / 127Vdc / 200Vdc / 220Vdc / 250Vdc)
- Functions Dual Digital Counter/Rate
- Order code / Manufacturer SKU LD4006P0
- Primary brand Red Lion
- Sub-range name LD series
- Design built-in batch counting capability
- Digital outputs 1 x digital output (setpoint reached)
- Benefits Available in 4 or 6 digits versions Single or dual counter with rate indicator Programmable scaling and decimal points Built-in batch counting capability Programmable user input Universally powered dual 5A Form C relay Aluminium NEMA 4x case construction
- Degree of protection IP65 NEMA 4X
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
