PAX2D000 Red Lion Industrial Automation Components

PAX2D000 on Advantage Electric Supply
Red Lion

Part#:PAX2D000

Manufacturer:Red Lion

Category:Industrial Automation Components

Product Lifecycle:Active

Product description

Red Lion PAX2D000 is a digital meter designed for strain gauge/load cell measurement applications. It features a 1/8 DIN size (96x48mm) with a display that includes 18mm red/orange/green and 14mm green digits, facilitating clear visibility. This meter offers three user inputs and connects via USB. It supports a wide range of supply voltages, including AC options from 50-250Vac (with specific values like 48Vac, 100Vac, up to 240Vac) and DC options from 21.6-250Vdc (including 24Vdc, 48Vdc, up to 250Vdc), making it versatile for various power supplies. The PAX2 series meter is designed with an IP65 NEMA 4X degree of protection, ensuring durability in different environments. It has a frequency range for analog input sampling rate from 5Hz to 160Hz and includes one analog input for strain gauge input with a 4-wire bridge or 2-wire single-ended configuration, offering 24-bits conversion for precise measurements. Additionally, it is equipped with three digital inputs (Sink/Source) for user-defined functionality.

Product Details

  • Display
    2 rows x positive image backlight LCD display 18mm 6-digits high red / orange / green characters (top row) 8.9mm high 9-digits green characters (bottom row)
  • Degree of protection
    IP65 NEMA 4X
  • Replaces
    GEM52060 GEM52160 PAXLC800 APLT0800
  • Primary brand
    Red Lion
  • Supply voltage (AC)
    50-250Vac (48Vac / 100Vac / 110Vac / 120Vac / 200Vac / 208Vac / 220Vac / 230Vac / 240Vac)
  • Functions
    Universal digital input counter / rate meter / tachometer
  • Order code / Manufacturer SKU
    PAX2D000
  • Main function
    Counter (Digital)
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
  • Sub-range name
    PAX2 series
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 UL Listed RoHS compliant
  • Product series / family name
    Process indicators
  • Supply voltage (DC)
    21.6-250Vdc (24Vdc / 48Vdc / 60Vdc / 72Vdc / 100Vdc / 110Vdc / 120Vdc / 127Vdc / 200Vdc / 220Vdc / 250Vdc)
  • Benefits
    Main display offers three programmable / easy-to-read colors (red / orange / green) The display color can be tied to the setpoints The 9-digits display accommodates totalizingapplications that exceed the normal 6-digits displays Stock one meter for multip
  • Design
    1/8 DIN (96x48mm) 18mm red/orange/green / 14mm green digits
  • Digital inputs
    2 x digital inputs (high-speed counters; Sink/Source; 35kHz max) (MAIN INPUTS) 2 x digital inputs (Sink/Source) (USER INPUT)
  • Mounting mode
    Flush / door

Product condition

New Factory Sealed

New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
