TESK-SU-12ST1 Schmersal Safety Switches
Part#:TESK-SU-12ST1
Alt. Part#:103005763
Manufacturer:Schmersal
Category:Safety Switches
Product Lifecycle:Active
Product description
TESK-SU-12ST1 Schmersal - Safety switch for hinged guards; Hinge safety switch; connector plug M12 bottom; adjustable switching angle; Standard hinge; Metal enclosure
Product Details
- Enclosure material Zinc die-cast
- Mechanical life, minimum 1,000,000 Operations
- Number of auxiliary contacts 1
- Note (Cable section) All indications about the cable section are including the conductor ferrules.
- Degree of protection IP65
- Rated insulation voltage Ui 30 V
- Alignment aid Yes
- Terminal Connector Connector M12
- Ambient temperature, minimum -25 °C
- Colour of the housing Silver
- Material of the contacts, electrical Silver-nickel alloy 10
- Width of sensor 78 mm
- Rated impulse withstand voltage Uimp 0.5 kV
- Switching frequency 1,200 /h
- Number of safety contacts 2
- Height of sensor 116 mm
- Thermal test current 2.5 A
- Switching principle Creep circuit element
- Gross weight 340 g
- Cable section, minimum 0.5 mm²
- Utilisation category AC-15 2 A
- Adjustable switching angle Yes
- Cable section, maximum 1 mm²
- Ambient temperature, maximum +65 °C
- Switching element NO contact, NC contact
- Mounting inside Yes
- Length of sensor 20 mm
- Utilisation category DC-13 24 VDC
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
The price of TESK-SU-12ST1 on Advantage Electric Supply is $286.00. Order now.
