.2536ES1BW56C-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 115/208-230 V
- Output Rating 0.25 HP
- Rated Speed 3485 rpm
- Flange Type C
- Terminal box¹ Left position
- Synchronous speed 3600 rpm
- Flange C
- Output rating 0.25 HP
- Number of poles 2
- Voltage 115/208-230 V
- Standard NEMA MG-1
- Approx. weight³ 16.7 lb
- Rotation¹ Both (CW and CCW)
- Noise level² 66.0 dB(A)
- Mounting F-1
- Degree of Protection IP55
- Altitude 1000 m.a.s.l.
- Ambient temperature -20°C to +40°C
- Duty Cycle Cont.(S1)
- Enclosure IC411 - TEFC
- Starting Method Direct On Line
- Service factor 1.15 (1.00 @ 208V)
- Temperature rise 80 K
- Moment of inertia (J) 0.0147 sq.ft.lb
- Insulation Class F
- Locked rotor time 19s (cold) 11s (hot)
- Design N
- Breakdown torque 300 %
- Rated torque 0.377 ft.lb
- No load current 3.20/1.38-1.60 A
- Locked rotor torque 290 %
- Number of Poles 2
- LRC 6.6x(Code P)
- Slip 3.19 %
- L. R. Amperes 27.7/15.3-13.8 A
- Frame W56C
- Rated speed 3485 rpm
- Rated current 4.20/2.32-2.10 A
- Output 0.25 HP (0.18 kW)
- Frequency 60 Hz
- Rated voltage 115/208-230 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
