00136OS1BJPR56C-S WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 115/208-230 V
- Output Rating 1 HP
- Rated Speed 3500 rpm
- Flange Type C
- Rated current 12.8/7.08-6.40 A
- Design N
- Noise level² 58.0 dB(A)
- Frame 56C
- Locked rotor time 14s (cold) 8s (hot)
- Altitude 1000 m.a.s.l.
- Number of poles 2
- Number of Poles 2
- Service factor 1.40 (1.00 @ 208V)
- Flange C
- L. R. Amperes 88.3/48.9-44.2 A
- No load current 8.40/3.62-4.20 A
- Rotation¹ CCW
- Moment of inertia (J) 0.0472 sq.ft.lb
- LRC 6.9x(Code M)
- Mounting F-1
- Temperature rise 80 K
- Frequency 60 Hz
- Duty Cycle Cont.(S1)
- Standard NEMA MG-1
- Voltage 115/208-230 V
- Output 1 HP (0.75 kW)
- Rated torque 1.50 ft.lb
- Insulation Class F
- Terminal box¹ Without Terminal Box
- Rated voltage 115/208-230 V
- Slip 2.78 %
- Locked rotor torque 260 %
- Ambient temperature -20°C to +40°C
- Synchronous speed 3600 rpm
- Breakdown torque 280 %
- Output rating 1 HP
- Rated speed 3500 rpm
- Starting Method Direct On Line
- Approx. weight³ 25.9 lb
- Enclosure IC01 - ODP
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
