00218OT3E56C-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 230/460 V
- Output Rating 2 HP
- Rated Speed 1740 rpm
- Flange Type C
- L. R. Amperes 41.4/20.7 A
- Temperature rise 80 K
- Design A
- Synchronous speed 1800 rpm
- Number of Poles 4
- Moment of inertia (J) 0.1168 sq.ft.lb
- Enclosure IC01 - ODP
- Flange C
- Slip 3.33 %
- Locked rotor time 30s (cold) 17s (hot)
- Mounting F-1
- Terminal box¹ Without Terminal Box
- Rated speed 1740 rpm
- Ambient temperature -20°C to +40°C
- Approx. weight³ 38.3 lb
- Breakdown torque 320 %
- Altitude 1000 m.a.s.l.
- Output rating 2 HP
- Output 2 HP (1.5 kW)
- No load current 2.75/1.38 A
- Rotation¹ Both (CW and CCW)
- Number of poles 4
- Frame 56HC
- Locked rotor torque 260 %
- Duty Cycle Cont.(S1)
- Standard NEMA MG-1
- Frequency 60 Hz
- Rated torque 6.04 ft.lb
- Noise level² 52.0 dB(A)
- Rated current 5.38/2.69 A
- Starting Method Direct On Line
- Insulation Class F
- Rated voltage 230/460 V
- LRC 7.7x(Code K)
- Service factor 1.15 (1.00 @ 208V)
- Voltage 230/460//190-220/380-415 V
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
