00318OS1C184T-S WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 208-230 V
- Output Rating 3 HP
- Rated Speed 1765 rpm
- Flange Type Without
- Rated speed 1765 rpm
- Moment of inertia (J) 0.2781 sq.ft.lb
- Standard NEMA MG-1
- Slip 1.94 %
- Temperature rise 80 K
- Starting Method Direct On Line
- Frequency 60 Hz
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Output 3 HP (2.2 kW)
- No load current 4.91-5.70 A
- Service factor 1.15 (1.00 @ 208V)
- Flange Without
- L. R. Amperes 95.9-89.6 A
- Locked rotor time 10s (cold) 6s (hot)
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Rated current 13.7-12.8 A
- Design L
- Voltage 208-230 V
- Frame 182/4T
- Rated torque 8.93 ft.lb
- Enclosure IC01 - ODP
- Output rating 3 HP
- Rated voltage 208-230 V
- Locked rotor torque 275 %
- Mounting F-1
- Number of poles 4
- Number of Poles 4
- Breakdown torque 245 %
- Ambient temperature -20°C to +40°C
- Synchronous speed 1800 rpm
- LRC 7.0x(Code H)
- Duty Cycle Cont.(S1)
- Approx. weight³ 66.1 lb
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
