00518EP3EHP184TYZ7F3 WEG AC Motors
Product Details
- Number of Poles 4 Pole
- Voltage 208-230/460 V
- Output Rating 5 HP
- Rated Speed 1765 rpm
- Flange Type Special
- Rated speed 1765 rpm
- No load current 10.0-9.04/4.52 A
- Duty Cycle S3
- Standard NEMA MG-1
- Rated current 16.3-14.7/7.37 A
- Locked rotor torque 300 %
- Ambient temperature -20°C to +40°C
- Synchronous speed 1800 rpm
- Number of Poles 4
- Design A
- Enclosure IC411 - TEFC
- Output rating 5 HP
- L. R. Amperes 148-134/67.1 A
- Moment of inertia (J) 0.3702 sq.ft.lb
- Altitude 1000 m.a.s.l.
- Voltage 208-230/460 V
- Slip 1.94 %
- Breakdown torque 420 %
- Number of poles 4
- Frequency 60 Hz
- Rated torque 14.9 ft.lb
- Noise level² 56.0 dB(A)
- Rated voltage 208-230/460 V
- Temperature rise 80 K
- Rotation¹ Both (CW and CCW)
- Frame 184TYZ
- Locked rotor time 23s (cold) 13s (hot)
- Degree of Protection IP55
- Terminal box¹ Top
- Output 5 HP (3.7 kW)
- Insulation Class F
- Approx. weight³ 88.2 lb
- Flange Special
- LRC 9.1x(Code M)
- Starting Method Direct On Line
- Mounting F-3
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
