00536ES1E184T-W22 WEG AC Motors
Product Details
- Number of Poles 2 Pole
- Voltage 208-230/460 V
- Output Rating 5 HP
- Rated Speed 3515 rpm
- Flange Type Without
- Rated current 20.5-19.0/9.50 A
- Temperature rise 80 K
- Mounting F-1
- Rated speed 3515 rpm
- Duty Cycle Cont.(S1)
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Frequency 60 Hz
- Insulation Class F
- Number of poles 2
- Frame 182/4T
- Moment of inertia (J) 0.2164 sq.ft.lb
- Enclosure IC411 - TEFC
- Rated voltage 208-230/460 V
- Rated torque 7.47 ft.lb
- Degree of Protection IP55
- Voltage 208-230/460 V
- Output 5 HP (3.7 kW)
- No load current 3.36-3.90/1.95 A
- Starting Method Direct On Line
- Noise level² 72.0 dB(A)
- LRC 7.1x(Code G)
- Breakdown torque 250 %
- Altitude 1000 m.a.s.l.
- Output rating 5 HP
- Number of Poles 2
- Service factor 1.15 (1.00 @ 208V)
- Approx. weight³ 108 lb
- Flange Without
- Slip 2.36 %
- Locked rotor torque 280 %
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
- L. R. Amperes 146-135/67.5 A
- Locked rotor time 12s (cold) 7s (hot)
- Synchronous speed 3600 rpm
Product condition
New Factory Sealed
New Factory Sealed - New condition, never used, original OEM part with original packaging and factory seal.
